A Line — A Series

Lat Pulldown / Seated Row

The AE8026 is a selectorized strength machine specifically engineered for back muscle training, integrating two core back exercises in a single unit designed to enhance back width and thickness systematically. The extended seat accommodates torso positioning for both lat pulldowns and seated rows, while the ultra-high pulley provides full range of motion for lat pulldowns. Features a 3+1 position adjustable thigh pad and ergonomic footplates matching natural stepping angles.

Dimensions2012 × 1469 × 2260 mm
Net Weight218.5 kg
Weight Stack Options105 kg
Maximum Weight Stack117.5 kg
Maximum Body Weight150 kg
Lat Pulldown Pulley Ratio1:1
Seated Row Pulley Ratio1:1
Main Frame TubingJ50 × 150 × 3.0 mm
